Z, ZM, T va Y seriyalari — IECEx sertifikatlangan
Portlashdan himoyalangan impuls klapani
Alangadan himoyalangan solenoid g'altak asosida qurilgan to'g'ri burchakli, tashqi rezbali, cho'mdiriladigan va to'g'ri oqimli portlashdan himoyalangan klapanlar — xavfli chang muhitlari uchun ishonchli, yuqori chastotali filtr tozalash va sertifikatlangan xavfsizlik muvofiqligi bilan ishlab chiqilgan.
To'liq model turkumi
Ex mb seriyasi, o'rnatish turi bo'yicha.
Ex mb IIC T6 Gb · IP65 · IECEx / CE / CCC / RoHS / EAC sertifikatlangan
| Turi | Model raqami | O'lcham (dyuym) | DN o'lchami | Ex himoya darajasi |
|---|---|---|---|---|
| To'g'ri burchakli | DCF-F-2L-B | 3/4″ | DN20 | Ex mb IIC T6 Gb |
| To'g'ri burchakli | DCF-F-Z-20 | 3/4″ | DN20 | Ex mb IIC T6 Gb |
| To'g'ri burchakli | DCF-F-Z-25 | 1″ | DN25 | Ex mb IIC T6 Gb |
| To'g'ri burchakli | DCF-F-Z-40S | 1.5″ | DN40 | Ex mb IIC T6 Gb |
| To'g'ri burchakli | DCF-F-Z-50S | 2″ | DN50 | Ex mb IIC T6 Gb |
| To'g'ri burchakli | DCF-F-Z-62S | 2.5″ | DN65 | Ex mb IIC T6 Gb |
| To'g'ri burchakli | DCF-F-Z-76S | 3″ | DN80 | Ex mb IIC T6 Gb |
| To'g'ri burchakli | DCF-F-Z-102S.B | 3.5″ | DN90 | Ex mb IIC T6 Gb |
| Tashqi rezba | DCF-F-ZM-20 | 3/4″ | DN20 | Ex mb IIC T6 Gb |
| Tashqi rezba | DCF-F-ZM-25 | 1″ | DN25 | Ex mb IIC T6 Gb |
| Tashqi rezba | DCF-F-ZM-40S | 1.5″ | DN40 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-Y-25 | 1″ | DN25 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-Y-40S | 1.5″ | DN40 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-Y-50S | 2″ | DN50 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-Y-62S | 2.5″ | DN65 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-Y-76S | 3″ | DN80 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-Y-102S.B | 3.5″ | DN90 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-Y-102S | 4″ | DN100 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DCF-F-YQ-76S | 3″ | DN80 | Ex mb IIC T6 Gb |
| Cho'mdiriladigan | DMY-F-II-80 | 3″ | DN80 | Ex mb IIC T6 Gb |
| To'g'ri oqimli | DCF-F-T-25S | G1″ | DN25 | Ex mb IIC T6 Gb |
| To'g'ri oqimli | DCF-F-T-40S | G1½″ | DN40 | Ex mb IIC T6 Gb |
| To'g'ri oqimli | DCF-F-T-50S | G2″ | DN50 | Ex mb IIC T6 Gb |
Mahsulot standartlari
Xavfli zonada ishlatish uchun sertifikatlangan.
SertifikatlarIECEx, Ex, CE, CCC, RoHS
IECEx darajasiEx mb IIC T6 Gb
Himoya darajasi (IP)IP65
O'rnatish talablari
Xavfsiz ishlash uchun sharoitlar.
Balandlik
1000 metrdan oshmasligi kerak
Nisbiy namlik
95% dan oshmasligi (+25°C da)
Xavfli muhitlar
1-zona yoki 2-zona, II sinf (T1–T4) yonuvchan gaz/bug' aralashmalari bilan, yoki 20-zona (A turi) yonuvchan chang bilan
Atrof-muhit atmosferasi
Izolyatsiyaga zarar yetkazishi mumkin bo'lgan gaz yoki bug'lardan xoli bo'lishi kerak
Barqarorlik
O'rnatish joyi sezilarli tebranish, zarba yoki vibratsiyadan xoli bo'lishi kerak
Himoya
Tomchilaydigan yoki sachraydigan suvdan uzoqda o'rnating
Mahsulot videolari
Tegishli namoyish va tanlov videolari.
Sertifikatlar
Ushbu mahsulot turkumi mustaqil tashkilot tomonidan sertifikatlangan.
Mahsulot sertifikati
DCF-F Series · DCF-F Series (2L-B / Z / Y / YA / YQ / ZM / T variants) · DMY-F-II-80
CCC sertifikati — DCF-F seriyali portlashdan himoyalangan impuls klapani
| Sertifikat raqami | 2024322307005851 |
|---|---|
| Bergan tashkilot | Shanghai Inspection and Testing Institute of Instruments and Automation Systems Co., Ltd. (SITIIAS) |
| Berilgan sana | 2024-07-16 |
| Amal qilish muddati | 2029-03-18 |
| Standartlar | GB/T 3836.1-2021, GB/T 3836.9-2021, CNCA-C23-01:2024 |
Mahsulot sertifikati
Qamrab olingan modellar (4)
DCF-Fa Series · DCF-Fa series · DCF-Fa Series (2L-B / Z / Y / YA / YQ / ZM / T variants) · DMY-Fa-II-80
CCC sertifikati — DCF-Fa seriyali portlashdan himoyalangan impuls klapani
| Sertifikat raqami | 2025322307006980 |
|---|---|
| Bergan tashkilot | Shanghai Inspection and Testing Institute of Instruments and Automation Systems Co., Ltd. (SITIIAS) |
| Berilgan sana | 2025-11-06 |
| Amal qilish muddati | 2030-11-05 |
| Standartlar | GB/T 3836.1-2021, GB/T 3836.9-2021, CNCA-C23-01:2024 |
Mahsulot sertifikati
DCF-F2 series · DCF-F2 series (Z/Y/T/ZM/2L-B variants, 20-115S sizes) · DMY-F2-II-80
CCC Ex sertifikati — DCF-F2 seriyali portlashdan himoyalangan impuls klapanlari
| Sertifikat raqami | 2024322307006147 |
|---|---|
| Bergan tashkilot | Shanghai Inspection and Testing Institute of Instruments and Automation Systems Co., Ltd. (SITIIAS) |
| Berilgan sana | 2024-08-20 |
| Amal qilish muddati | 2029-08-19 |
| Standartlar | GB/T 3836.1-2021, GB/T 3836.2-2021, GB/T 3836.31-2021 |
Mahsulot sertifikati
DCF-F3 series · DCF-F3 series (Z/Y/T/ZM/2L-B variants, 20-115S sizes) · DMY-F3-II-80
CCC Ex sertifikati — DCF-F3 seriyali portlashdan himoyalangan impuls klapanlari
| Sertifikat raqami | 2024322307006175 |
|---|---|
| Bergan tashkilot | Shanghai Inspection and Testing Institute of Instruments and Automation Systems Co., Ltd. (SITIIAS) |
| Berilgan sana | 2024-09-05 |
| Amal qilish muddati | 2029-09-04 |
| Standartlar | GB/T 3836.1-2021, GB/T 3836.2-2021, GB/T 3836.9-2021, GB/T 3836.31-2021 |
Texnik chizmalar
Ushbu mahsulot uchun o'rnatish o'lchamlari.
🔒 O'lchamlar so'rov bo'yicha taqdim etiladiDCF-F-Y-102S
DCF-F-Y-102S · 4" · portlashdan himoyalangan botiriladigan impuls klapani — O'rnatish chizmasi
| Mounting spacing | 225 mm |
|---|---|
| Overall height | 211 mm |
| Flange diameter | 🔒 |
| Inner step 1 | 191 mm |
| Inner step 2 | 🔒 |
| Inner bore | 🔒 |
+17 yana o'lchamlar
🔒 O'lchamlar so'rov bo'yicha taqdim etiladiDMY-F-II-80
DMY-F-II-80 · II-80 (taxminan 3") · portlashdan himoyalangan botiriladigan impuls klapani — O'rnatish chizmasi
| Mounting spacing | 212 mm |
|---|---|
| Overall height | 198 mm |
| Seat height 1 | 38 mm |
| Seat height 2 | 🔒 |
| Seal bore | 🔒 |
| Inner step | 🔒 |
+13 yana o'lchamlar
🔒 O'lchamlar so'rov bo'yicha taqdim etiladiDCF-F-YQ-76S(standard O-ring)
DCF-F-YQ-76S(standart O-halqa) · 3" · portlashdan himoyalangan ixcham botiriladigan impuls klapani — O'rnatish chizmasi
| Mounting spacing | 195 mm |
|---|---|
| Overall height | 🔒 |
| Seat height 1 | 🔒 |
| Seat height 2 | 🔒 |
| Inner bore | Ø94 mm |
| Body flange | 158 mm |
+12 yana o'lchamlar
Bilimlar bazasi
Ushbu mahsulot bo'yicha amaliy javoblar.
Nosozliklarni bartaraf etish
Xiechang portlashdan himoyalangan solenoid g'altagini qanday ulash kerak?
① va ② simlar kirish signal simlari, ③ esa yerga ulash klemmasi; g'altak korpusida alohida yerga ulash klemmasi ham mavjud.
portlashdan himoyalangan g'altakulashsolenoid
Mahsulot savol-javoblari
DCF-F model kodi nimani anglatadi?
DCF-F-[material]-[o'lcham]-[korpus turi], bunda F/F2/F3 portlashdan himoyalanish konstruksiyasini, Z/ZM/Y/T esa korpus uslubini bildiradi.
DCF-Fmodel kodinomlash qoidasi
Mahsulot savol-javoblari
Ex mb IIC T4 Gb kabi portlashdan himoyalanish belgisini qanday o'qish kerak?
Har bir segment himoya turini, gaz/chang guruhini va maksimal sirt haroratini bildiradi.
Ex belgisiportlashdan himoyalanish belgisiIIC
Afzalliklar
Xiechang DCF-F impuls klapanlari qanday portlashdan himoyalanish (Ex) sertifikatiga ega?
DCF-F seriyasi (Z / Y / ZM / T / 2L-B, barcha o'lchamlar) GB/T 3836 standartlariga muvofiq GYB25.1974X Ex sertifikatiga ega, IP65 / IP67 himoya darajasi bilan.
Ex sertifikatiGYB25.1974XGB/T 3836
Afzalliklar
Xiechang portlashdan himoyalangan impuls klapanlari qanday CCC (Xitoy Majburiy Sertifikatsiyasi) sertifikatiga ega?
F, F2 va F3 portlashdan himoyalangan seriyalarining har biri CCC sertifikatiga ega (masalan, F seriyasi uchun No. 2024322307005851).
CCC sertifikatsiyasiXitoy Majburiy Sertifikatsiyasi2024322307005851
Texnik xususiyatlar
Xiechang portlashdan himoyalangan elektromagnit impuls klapanlarining texnik parametrlari qanday?
Nominal bosim 0.2–0.6 MPa, nominal kuchlanish DC24V±10% yoki AC220V±10%, ish muhiti siqilgan gaz, nisbiy namlik ≤85%.
portlashdan himoyalangan impuls klapanitexnik parametrlarnominal bosim
